Medistrom Portable CPAP Battery Pack (12v or 24v Model)

Portable CPAP Battery For Travel

The Pilot-24 Lite and Pilot-12 Lite are a revolutionary CPAP & BiLevel power solution combining an ultra-portable travel battery with a backup power supply so you can be sure to have power at home or on the road whenever you need it. The Medistrom battery should provide 1-2 nights of power for your CPAP. As an added bonus the battery has a built in USB port for charging phones, or other small electronics, and a handy integrated flashlight too!

https://www.youtube.com/watch?v=rA0AVSNClws

Light & Powerful For Travel

Whether you're on the road, in the air, or far off the beaten path the Pilot-12 Lite and Pilot-24 Lite have the power you need to get you where you're going in a lightweight, sturdy aluminium package built for travel.

An Ideal CPAP Battery Backup Power Option For Home

Not only is the CPAP battery great for travel, it's an ideal backup power solution for home too. Attach the Pilot-24 Lite or Pilot-12 Lite in series between your CPAP and the wall and then rest is simple... If your power goes out, due to a storm or other anomaly, the Pilot Lite will take over automatically ensuring you continue to receive restful, uninterrupted sleep therapy. When the power comes back on the Pilot Lite will automatically recharge so it's ready the next time you need it.

Extra Features For Added Value

As an added bonus the Medistrom Pilot Lite CPAP battery includes some intelligent extras as well: there's a built in USB port for charging other small electronic devices like phones, cameras or tablets; and there's a handy LED flashlight built into the battery case so you can have a little extra light whenever you need it. It's great for reading before you fall asleep!

Convenient AC Charging & Optional DC Charger Available

• The Pilot 24 Lite Battery Pack charges using the AC Power Cord from any compatible CPAP or BiLevel machine, so there's no extra charging cord needed. To make things even easier, LED lights on the battery let you know the battery's current charge status.
• There's also a DC Power Charger available as an optional add on for the Pilot Lite, so if you'd like to charge from the cigarette style power outlets found in most cars, boats and other vehicles you can upgrade and do that too.

Great For Use On Aeroplanes

Current FAA regulations allow Sleep Apnea Therapy Devices (CPAP & BiPAP Machines) and Lithium Ion Batteries (like the one in this battery pack) to be carried onboard commercial flights and are usually not counted toward your weight limits; however it is always important to check with your airline prior to travel to determine exactly what requirements they have for carrying medical equipment on board.

Medistrom Pilot Lite Device Compatibility

The Pilot-12 Lite can be used with ONLY the following APAP/CPAP devices:

• Phillips Respironics System One S60
  • DC input cables included
• Phillips Respironics DreamStation 1
  • DC input cables included
• Phillips Respironics DreamStation 2
  • DC input cables included
• DeVilbiss IntelliPAP I and IntelliPAP II
  • DC input cables sold separately here, (SKU:MDS.ACC.0011, MPN:P12MXDPLK)
• HDM Z1 and HDM Z2
  • DC input cables sold separately here, (SKU:MDS.ACC.0011, MPN:P12MXDPLK)

The Pilot-24 Lite can be used with ONLY the following APAP/CPAP devices:

• ResMed AirSense 11 Series
  • DC input cables sold separately here, (SKU:MDS.ACC.0015, MPN:P24R11PLK)
  • Recharge battery using AirSense 11 power cable and adaptor kit linked above.
• ResMed AirSense 10 series
  • DC input cable included with battery,
  • Quick recharge using AirSense 10 power cable.
• ResMed AirMini
  • DC input cable included with battery,
  • Slow recharge using AirMini power cable and included adaptor, quicker charge cable available here.
• Phillips Respironics DreamStation Go
  • DC input cables sold separately here, (SKU:MDS.ACC.0005, MPN:P24PDGPLK)
  • Quick recharge cable included with above kit.
• BMC Luna G3
  • DC input cables sold separately here, (SKU:MDS.ACC.0005, MPN:P24PDGPLK)
  • Quick recharge cable included with above kit.
• ResMed S9 series
  • DC input cables sold separately here, (SKU:MDS.ACC.0006, MPN:P24R09PLK)
  • Fast recharging using ResMed S9 power cord and included kit adaptor linked on the line above.
• Apex iCH series
  • DC input cables sold separately here, (SKU:MDS.ACC.0008, MPN:P24AMIPLK)
  • Fast recharging using APEX iCH power cord and included kit adaptor linked on the line above.
• SmartMED iBreeze
  • DC input cables sold separately here, (SKU:MDS.ACC.0008, MPN:P24AMIPLK)
  • Additional quicker charge cable required here, SKU:MDS.ACC.0007 MPN:P24CCAACA)
• Lowenstein prismaSMART series
  • DC input cables sold separately here, (SKU:MDS.ACC.0009, MPN:P24LPSPLK)
  • Fast recharging using prismaSMART power cord and included kit adaptor linked on the line above.
• Sefam S.Box series device
  • DC input cables sold separately here, (SKU:MDS.ACC.0008, MPN:P24AMIPLK)
  • Fast recharging using APEX iCH power cord and included kit adaptor linked on the line above.
• BMC M1 Mini device
  • DC input cables sold separately here, (SKU:MDS.ACC.0008, MPN:P24AMIPLK)
  • Fast recharging using APEX iCH power cord and included kit adaptor linked on the line above.

To Make The Battery Last Longer

Follow the below instructions to disable humidifier and heated tubing, and setting Climate Control to Manualfor the ResMed AirSense 10

1. Make sure your heated tubing and water reservoir/humidifier is connected to your CPAP device.
2. Turn on your AirSense 10 and you should see two options (My Options and Sleep Report)
3. Highlight My Options by turning the dial to the right of the screen andpressingit to select it.
4. We would recommend recording these 3 settings on paper in case you want to revert them back to normal afterwards.

• These settings areclimate ctrl,humidity level, andtube temp.
• *Note if climate ctrlis on automatic, you will not see the humidity level option*

5. In My Options, turn the dial untilclimate ctrl is highlighted, press the dial to select it. This option must be onManualto disable both the humidifier and heated tubing. Press the dial to confirm.
6. Next humidity level must be highlighted and selected. If it is set on a setting from 1-8, the dial must be turned all the way to the left until yousee off. Press the dial to confirm this option.
7. Lastly, scroll down to tube temperature and you should see a temperature. the dial must be turned all the way to the left until you see off. Press the dial to confirm this option.

User Manual & Documents

Product manual for Medistrom Pilot-12 Lite & Medistrom Pilot-24 Lite Battery and Backup Power Supply HERE

Travel Letter for Medistrom HERE
